The TOTAL TMT46003 Digital AC Clamp Meter is a professional measuring instrument designed for electricians, maintenance technicians, HVAC professionals, and industrial users. With the ability to measure up to 600A AC current without disconnecting circuits, it provides safe, fast, and accurate electrical testing for residential, commercial, and industrial applications.
Featuring a large 6000-count LCD display with dual-color backlight, the TMT46003 measures AC current, AC/DC voltage, resistance, capacitance, and includes Non-Contact Voltage (NCV) detection for enhanced safety. Additional functions such as data hold, flashlight, diode testing, and auto power-off make it a versatile diagnostic tool for everyday electrical work.
Key Features
- Measures AC current up to 600A
- 6000-count LCD display with dual-color backlight
- AC and DC voltage measurement up to 600V
- Non-Contact Voltage (NCV) detection
- Resistance and capacitance measurement
- Data hold function for easy reading
- Built-in flashlight for low-light work areas
- Diode testing capability
- Auto power-off function
- Low battery indication
- Compact and ergonomic clamp design
- Ideal for electrical maintenance, troubleshooting, and inspection work
Specifications
| Specification | Value |
|---|---|
| Brand | TOTAL |
| Model | TMT46003 |
| Display | 6000 Count LCD |
| Backlight | Dual-Color Backlight |
| AC Current | 4A / 40A / 400A / 600A |
| AC Voltage | 4V / 40V / 400V / 600V |
| DC Voltage | 400mV / 4V / 40V / 400V / 600V |
| Resistance | 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ |
| Capacitance | 4nF / 40nF / 400nF / 4μF / 40μF / 400μF / 4mF |
| NCV Detection | Yes |
| Data Hold | Yes |
| Flashlight | Yes |
| Diode Test | Yes |
| Auto Power Off | Yes |
| Battery Type | 2 × AAA Batteries |
| Safety Category | CAT III 600V |
Package Includes
- 1 × TOTAL TMT46003 Digital AC Clamp Meter
- 2 × AAA Batteries
- User Manual
- Color Box Packaging
